Default No Water..... Help !

This afternoon my wife went to turn on kitchen faucet, and no water !
I then went into the bath-room off kitchen and turned on water, with same results.

First thought, was the circuit-breaker fuse to the pump triggered for some reason ? Checked fuse breaker and all looked ok, but reset anyway.
Tried faucet again, but still no water.

Next, checked the pressure to the water ‘holding tank’,
it was at zero pounds pressure.

So now I’m think I may have one of two problems here:
1. The holding tank is dead and can’t hold air. OR
2. Pump in the well has died
Holding tank, pump and Well are original, 16 years old

Thoughts on what the underlying issue is ?
Recommendations for pump service ?
(I’m in Gilford, and know Gilford Well services this area, but would like other recommendations also)

In the mean time I'm lugging jugs of water to bath-room to flush toilets.
Wife not happy !

Thanks !
bigdog is offline   Reply With Quote
Old 08-28-2022, 07:15 PM   #2
John Mercier
Senior Member

Join Date: Jun 2021
Posts: 2,151
Thanks: 2
Thanked 395 Times in 330 Posts
Default

The pump would push water past the tank if the tank bladder had failed.
Just the pump would need to start immediately every time there was a call for any water and it may cause some ''banging'' of the pipes.

The pump may have burned out, the impellers may have degraded, or the wire to the pump may have shorted.
John Mercier is offline   Reply With Quote
Old 08-28-2022, 08:13 PM   #3
bigdog
Senior Member

bigdog's Avatar

Join Date: Apr 2006
Location: Central MA-Gilford
Posts: 1,361
Thanks: 277
Thanked 108 Times in 89 Posts
Default Problem has been identified !

Problem has been identified ! I believe the pump 'pressure switch' is the issue.
Pressure switch is mounted on a 1/4-in tube near the pressure tank.

I was able to trouble-shoot the cause and solution from this website.
https://www.familyhandyman.com/proje...nd-diy-repair/

I have attached a picture of my pump switch. The 1/4" pipe I tapped is shown below the switch box.

They stated that if banging on the tube under the pressure switch kicks on the well pump, it means the contact surfaces of the electrical contacts are pitted or burned, on the pump switch causing a poor connection.

So I banged on the 1/4-in tube under the pressure switch, and darn if that do the trick. Water flowing again as normal. Wife happy again !!!!

I'll check the switch contacts for pitting and burning, and clean all electrical contacts, with nail/emory file. Will contact a plumber/electrician to replace pressure switch. Switch are fairly cheap, it will be the labor that will cost.

Thanks for your responses, much appreciated !
Attached Images


Last edited by bigdog; 08-28-2022 at 08:18 PM. Reason: typo
bigdog is offline   Reply With Quote
The Following User Says Thank You to bigdog For This Useful Post:
TCC (08-28-2022)
Old 08-28-2022, 08:26 PM   #4
fatlazyless
Senior Member

fatlazyless's Avatar

Join Date: Apr 2004
Posts: 8,295
Blog Entries: 1
Thanks: 280
Thanked 917 Times in 666 Posts
Default

You should pretty much be okay to replace the pressure switch with a new identical pressure switch as opposed to hiring a $250-electrician to do it.

For unscrewing the 1/2" diameter round collar nuts that hold the metal housing to the conduit use a medium flat screwdriver and a hammer and just tap-tap-tap the two around counter-clockwise and the two collars will come unscrewed.

Just make it all identical to what's there now and don't mess with the setting on the new $30 pressure switch.
__________________
... down and out, liv'n that Walmart side of the lake!
fatlazyless is offline   Reply With Quote
Old 08-28-2022, 09:48 PM   #5
John Mercier
Senior Member

Join Date: Jun 2021
Posts: 2,151
Thanks: 2
Thanked 395 Times in 330 Posts
Default

Mine started out as that...
Then after changing that out it was determined that the wires running down the well to the pump had corroded causing the switch to ''fuse'' open.

Daniel's jumped the wire (cut out the old and tied in with new wire), taped it back up tight and replaced the torque arrestors.
John Mercier is offline   Reply With Quote
Sponsored Links
Old 08-29-2022, 09:19 AM   #6
bigdog
Senior Member

bigdog's Avatar

Join Date: Apr 2006
Location: Central MA-Gilford
Posts: 1,361
Thanks: 277
Thanked 108 Times in 89 Posts
Default Plumbing Supplies ?

Besides F.W. Webb, where do the Pro's shop for plumbing supplies ?

In my case I will need a 'pressure switch' for my water system as described in previous Post.

Thanks in advance......
bigdog is offline   Reply With Quote
Old 08-29-2022, 09:27 AM   #7
Little Bear
Senior Member

Join Date: Jul 2006
Posts: 538
Thanks: 90
Thanked 212 Times in 111 Posts
Default

Quote:
Originally Posted by bigdog View Post
Besides F.W. Webb, where do the Pro's shop for plumbing supplies ?

In my case I will need a 'pressure switch' for my water system as described in previous Post.

Thanks in advance......
Try these guys in Alton: https://waterindustriesllc.com/
Little Bear is offline   Reply With Quote
Old 08-29-2022, 09:27 AM   #8
John Mercier
Senior Member

Join Date: Jun 2021
Posts: 2,151
Thanks: 2
Thanked 395 Times in 330 Posts
Default

Granite Group.
Behind the old Pepi Hermann shop across from the Laconia Airport.
Waterford Place
John Mercier is offline   Reply With Quote
Old 08-29-2022, 10:52 AM   #9
bigdog
Senior Member

bigdog's Avatar

Join Date: Apr 2006
Location: Central MA-Gilford
Posts: 1,361
Thanks: 277
Thanked 108 Times in 89 Posts
Default

Quote:
Originally Posted by John Mercier View Post
Granite Group.
Behind the old Pepi Hermann shop across from the Laconia Airport.
Waterford Place
Thanks John, I will stop there tomorrow after going to Gilford Recycling center.

The pressure switch is a Square D, very common brand, so fairly sure Granite Group would carry this item
bigdog is offline   Reply With Quote
Old 08-29-2022, 11:04 AM   #10
bigdog
Senior Member

bigdog's Avatar

Join Date: Apr 2006
Location: Central MA-Gilford
Posts: 1,361
Thanks: 277
Thanked 108 Times in 89 Posts
Default

Quote:
Originally Posted by John Mercier View Post
Granite Group.
Behind the old Pepi Hermann shop across from the Laconia Airport.
Waterford Place
John...
Granite Group has my part... $22

In the meantime I popped off pressure switch cover (power off of course)
and cleaned the 4 contact points with emory board, and a little 100 grit sandpaper. I noticed some pitting on points, so cleaned them up.
Hopefully be OK until I get new switch installed.

Reminds me of cleaning the points in my car distributor, back in the day, same principal.

Thanks again !

Last edited by bigdog; 08-29-2022 at 04:13 PM.
bigdog is offline   Reply With Quote
Old 08-29-2022, 05:05 PM   #11
SteveO123
Senior Member

Join Date: Jul 2010
Location: Laconia, Lake Opechee
Posts: 166
Thanks: 286
Thanked 80 Times in 43 Posts
Default

Make sure the 1/4 pressure hose is clear too. Mine used to get mucked up, blocking the pressure from the pump side to the switch. I reamed the gunk out with a small piece of wire .
